Front drum hydraulic winch 15 kN capacity
Availability:
zapytaj o cenę
On warehouse:
0
Producer:
Tema Italy
Product code:
109T1,5
- ask about price
-
ask about product
-
recommend to a friend
Description
Drum dimensions ø
350 x 620 mm
Drum capacity
400 m rope Ø 12 mm
Weight without rope
1260 kg
Technical data
| Drum dimensions ø | 350 x 620 mm |
|---|---|
| Drum capacity | 400 m rope Ø 12 mm |
| Weight without rope | 1260 kg |
| Performance | |
| Max pull | 15 kN |
| Max speed | 70 m/min |
| Speed at max pull | 25 m/min |
Engine
Diesel (25 hp) 19 kW
Cooling Liquid
Emission standard - (UE)2016/1628 Stage V
Standard features
- 1 hydraulic circuit with negative brake system
- 1 dynamometer for direct reading of pulling value with load-limiter device
- 300 m rope HMPE Ø 12 mm • Remote control unit c/w console 5 m cable
- Front stabilizer jack
- Back support by adjustable mechanical sprag
- Metallic cover can be opened on three sides
- On board toolbox
- Road trailer kit 1350 kg capacity with height adjustable drawbars and jockey wheel
- Upper lifting attachment point balanced type and anchoring attachments
Optional equipment
04-PW Radio control unit
13-PW Pre-heater (up to -30°C)
30-PW Spare wheel
34-PW Pressure roller on the drum
