Hydraulic cable winch 35 kN
Description
PARAMETERS FEATURES AND OPTIONS
Maximum load of 35 kN
Speed at maximum load 13m/min
Maximum speed 45m/min
Force at maximum speed 10 kN
Winches 200 mm
Maximum rope diameter 10 mm
Weight of the complete set with rope 2240 kg
ENGINE
Diesel (25.0 hp) 19 kW
Cooling : liquid
Start - electric
DIMENSIONS
Length 3200 mm
Height 1500 mm
Width 1700 mm
BASIC OPTIONS on equipment for additional pricing
Anti-scratch rope 10 mm in section 1000 m
Homologation for moving on the road up to 80 km/h
FEATURES AND OPTIONS
Standard features:
- One hydraulic circuit with negative braking system
- Control panel equipped with LCD touch screen 7" display, which includes: settings for maximum pulling force and instant indication of force , counter, speed indicator Hourly rate
- USB output for data recording
- Remote control c/w console 5 m cable
- 1600 kg (80 km/h) road kit
- Levelled hook for lifting the winch
ADDITIONAL EQUIPMENT - OPTIONS
04-PW Wireless remote control
13-PW Motor heater to -30 °C
Shipping costs
The price does not include any possible payment costs
